Status Indicator RAPs
Workcentre PE 220 11/05 2-13
10 Cover Open RAP
Description
The Cover Open message appears on the LCD even when the print cover is closed.
The Cover Open message does not appear on the LCD even when the print cover is open.
Check and Cause Solution
1. The ‘Open Cover’ microswitch may be
stuck or faulty
1. Use TECH mode (“cover sensor test”),
GP 4, to check the relevant cover switch oper-
ation. Check and replace the switch if neces-
sary, PL 1.
Note: The front cover microswitch is on the
HVPS. The rear cover microswitch is on the
SMPS.
2. The tab on the front cover may be dam-
aged or broken.
2. Replace the front cover, PL 1.
3. Check the connector and cables between
HVPS and Main PBA, SMPS and Main PBA
3. Install a new harness as necessary, PL 1.
Reseat the connectors. Replace the Main
Control board, PL 1, or HVPS, PL 1, or
SMPS, PL 1, as necessary.
