Status Indicator RAPs
Workcentre PE 220 11/05 2-5
2 JAM 0 RAP
Description
Paper is not exited from the cassette.
Jam-0 occurs if the paper feeds into the machine.
Check and Cause Solution
1. Check the Solenoid by using Engine Test
Mode-Pick up Test.
1. Replace the solenoid, PL 6.
2. Check the paper guides in the cassette. 2. Adjust the paper guides.
Install new parts as necessary, PL 1.
3. Check the surface of the roller-pickup for
foreign matter.
3. Clean with soft cloth dampened with IPA
(Isopropyl Alcohol) or water.
4. If the paper feeds into the machine and
Jam 0 occurs, perform Engine Test Mode-
Feed Sensor Test. Refer to GP 4.
4. Replace the SMPS, PL 1, HVPS, PL 1 or
feed sensor actuator, PL 6.
To Next Page
