Xilinx ZCU102 User Manual

ZCU102 Evaluation Board User Guide www.xilinx.com 13
UG1182 (v1.2) March 20, 2017
Chapter 2: Board Setup and Configuration
Table 2-1: ZCU102 Board Components
Callout Ref. Des. Feature/Component Notes
Schematic
0381449
Page Number
1
U1 Zynq UltraScale XCZU9EG MPSoC
with fan sink on soldered FPGA
XCZU9EG-2FFVB1156I
Radian FA35+K52B+T710
2
J1 PS-Side: DDR4 SODIMM Socket
with SODIMM
LOTES ADDR0067-P001A
Micron
23
3
U2 DDR4 Component Memory, (4 Gb) Micron
MT40A256M16GE-075E:B
25
4
U119, U120 Quad-SPI Flash Memory (MIO 0–12) (1 Gb total) Micron
MT25QU512ABB8ESF-OSIT
46
5
U116, J96 USB 3.0 Transceiver and USB 2.0 ULPI PHY (USB
micro-AB connector)
SMCS USB3320-EZK, KYON
KMMX-AB10-SMT1SB30TR
51
6J100SD Card Interface (connector) Hirose DMIAA-SF-PET(21) 47
7
U21/J2 Programmable Logic JTAG Programming Options
(module with separate USB Micro-B conn.)
Digilent JTAG_2_NC,
Hirose ZX62D-AB-5P8
22
8
U42 Programmable User Clock
(300 MHz default, 3.3V LVDS)
Silicon Labs
SI570BAB001614DG
40
9
U56 Programmable User MGT Clock
(156.250 MHz default, 3.3V LVDS)
Silicon Labs SI
SI570BAB001544DG
40
10
U69 SI5341B 10 Independent Output Any-Frequency
Clock Generator (PS Reference Clock) (I2C
programmable any frequency clock generator)
Silicon Labs
SI5341B-B05071-GM 39
11 U20 SFP/SFP+ Clock Recovery (jitter attenuated clock) Silicon Labs SI5328B-C-GMR 41
12
U98/P12 Ethernet PHY LED Interface Ethernet PHY U98 with
P12 RJ45 with magnetics
TI DP83867IRPAP,
Wurth 7499111221A
52
13
U40/J83 CP2108 USB UART Interface (bridge IC/USB Micro-B
connector)
Silicon Labs CP2108-B02-GM,
Hirose ZX62D-AB-5P8
42
14
U94/P7 HDMI Video Output (controller/connector) TI SN65DP159RGZ,
TEC Connectivity 1888811-1
35
15
U60, U61,
U97
I2C0 (MIO 14-15) bus switch and expanders) TI PCA9544ARGYR, 2 ea.
TI TCA6416APWR
57
16 U34, U135 I2C1 (MIO 16-17) bus switches TI TCA9548APWR, 2ea. 58
17
J54 SFP/SFP+ Connector (quad) Allbest
R-OP-008080-6-F-N-26-F63
34
18 U41 TI MSP430 System Controller TI MSP430F5342 38
19
J55/J87 User PMOD GPIO Headers
(PMOD0-RA receptacle/PMOD1-vert. male pin hdr.)
SULLINS PPPO062LJBN-RC,
SULLINS PBC36DAAN
55
20
J160 For more information about PMOD connector
compatible PMOD modules, see [Ref 23]. (PMOD I2C
RA receptacle)
SULLINS PPPO062LJBN-RC
49
21 DS37-DS44 User I/O (8 LEDs) GPIO LEDs, GREEN 0603 53
22 SW13
User I/O (8-pole DIP switch) C&K SDA08H1SBD 53
23
SW14-SW18 User I/O (pushbutton switches, active High) E-Switch TL3301EP100QG
placed in N, S, W, E, C pattern
53
Send Feedback
