Xilinx ZCU102 User Manual

ZCU102 Evaluation Board User Guide www.xilinx.com 33
UG1182 (v1.2) March 20, 2017
Chapter 3: Board Component Descriptions
Quad-SPI Flash Memory (MIO 0–12)
[Figure 2-1, callout 4]
The Micron dual MT25QU512ABB8ESF serial NOR flash Quad-SPI memories are capable of
holding the boot image for the MPSoC system. To achieve higher performance two
Quad-SPI devices are connected in parallel and provide an 8-bit data bus for booting and
configuration. This interface is used to support QSPI32 boot mode as defined in the Zynq
UltraScale+ MPSoC Technical Reference Manual (UG1085) [Ref 2].
The dual Quad-SPI flash memory located at U119/U120 provides 1 Gb of non-volatile
storage that can be used for configuration and data storage.
• Part number: MT25QU512ABB8ESF-0SIT (Micron)
• Supply voltage: 1.8V
• Datapath width: 8 bits
• Data rate: Various depending on Single/Dual/Quad mode
The connections between the SPI flash memory and the XCZU9EG MPSoC are listed in
Table 3-6.
The configuration and Quad-SPI section of the Zynq UltraScale+ MPSoC Technical Reference
Manual (UG1085) [Ref 2] provides details on using the Quad-SPI flash memory. For more
QSPI details, see the Micron MT25QU512ABB8ESF-0SIT data sheet at the Micron website
[Ref 13].
Table 3-6: Quad-SPI Component Connections to FPGA U1
XCZU9EG
(U1) Pin
Net Name
Quad-SPI U119 (LWR), U120 (UPR)
Pin Number Pin Name
AH16 MIO4_QSPI_LWR_DQ0 15 DQ0
AJ16 MIO1_QSPI_LWR_DQ1 8 DQ1
AD16 MIO2_QSPI_LWR_DQ2 9 DQ2_WP_B
AG16 MIO3_QSPI_LWR_DQ3 1 DQ3_RST_HOLD_B
AF16 MIO0_QSPI_LWR_CLK 16 C
AM15 MIO5_QSPI_LWR_CS_B 7 S_B
AE17 MIO8_QSPI_UPR_DQ0 15 DQ0
AP15 MIO9_QSPI_UPR_DQ1 8 DQ1
AH17 MIO10_QSPI_UPR_DQ2 9 DQ2_WP_B
AF17 MIO11_QSPI_UPR_DQ3 1 DQ3_RST_HOLD_B
AJ17 MIO12_QSPI_UPR_CLK 16 C
AD17 MIO7_QSPI_UPR_CS_B 7 S_B
