VB3/ V5 / VB 5 series inverter
18
The relationship between m ain circuit terminals and inverter types:
M ain circuit I/O terminals are shown in table 2-1:
Table
Table
Table
Table 2-1
2-1
2-1
2-1 main
main
main
main circuit
circuit
circuit
circuit I/O
I/O
I/O
I/O terminals
terminals
terminals
terminals
Fig. A
Fig. B
Fig. C
Fig. D
Fig. E
Fig. F
Fig. G
V oltage level
Power (KW)
Figure
T ype
220V
0.4 ～ 0.75
Fig. A
VB3
1.5
Fig. B
VB5
380V
1.5 ～ 3.7
Fig. C
VB5
5.5 ～ 7.5
Fig. D
VB5
11 ～ 18.5
Fig. E
V5
22 ～ 30
Fig. F
V5
37 ～ 55
Fig. G
V5
V oltage
T erminal
F unction
VB3 、 VB5 series
S ingle phase 220V
L 、 N
S ingle phase AC 220V input
U 、 V 、 W
T hree phase AC output
PE
G rounding
VB5 series
T hree phase 380V
L1 、 L2 、 L3
T hree phase AC 380V input
R 、 S 、 T
T hree phase AC 380V input
P+ 、 PB
B raking resistor
P+ 、 P-
G eneratrix + and -
U 、 V 、 W
T hree phase AC output
PE
G rounding
V5 series
T hree phase 380V
R 、 S 、 T
T hree phase AC 380V input
U 、 V 、 W
T hree phase AC output
P+ 、 P-
G eneratrix + and -
P 1 、 PB
B raking resistor
PE
G rounding
