Yamaha XT660R S Service Manual

3 - 52
CHK
ADJ
CHECKING AND LUBRICATING THE CABLES/
LUBRICATING THE LEVERS AND BRAKE PEDAL/
LUBRICATING THE SIDESTAND
EAS00170
CHECKING AND LUBRICATING THE
CABLES
The following procedure applies to all of the
inner and outer cables.
WARNING
_
Damaged outer cable may cause the cable
to corrode and interfere with its movement.
Replace damaged outer cable and inner
cables as soon as possible.
1. Check:
• outer cable
Damage
→
Replace.
2. Check:
• cable operation
Rough movement
→
Lubricate.
NOTE:
_
Hold the cable end upright and pour a few
drops of lubricant into the cable sheath or use
a suitable lubricating device.
Recommended lubricant
Engine oil or a suitable cable
lubricant
EAS00171
LUBRICATING THE LEVERS AND BRAKE
PEDAL
Lubricate the pivoting point and metal-to-metal
moving parts of the levers and brake pedal.
Recommended lubricant
Lithium-soap-based grease
EAS00172
LUBRICATING THE SIDESTAND
Lubricate the pivoting point and metal-to-metal
moving parts of the sidestand.
Recommended lubricant
Lithium-soap-based grease

Yamaha XT660R S Specifications

General

Displacement	660 cc
Bore x Stroke	100.0 mm x 84.0 mm
Compression Ratio	10.0:1
Fuel System	Fuel Injection
Ignition System	TCI
Starter System	Electric
Transmission System	5-speed
Final Drive	Chain
Front Suspension System	Telescopic forks
Front Tyre	90/90-21 M/C 54S
Rear Tyre	130/80-17 M/C 65S
Overall Width	865 mm
Overall Height	1, 230 mm
Seat Height	865 mm
Wheelbase	1, 505 mm
Wet Weight	181 kg
Fuel Tank Capacity	15 litres
Oil Tank Capacity	2.9 litres
Engine Type	Liquid-cooled, 4-stroke, single cylinder, SOHC
Maximum Power	48hp (35kW) @ 6, 000rpm
Frame	Steel diamond
Rear Suspension System	Swingarm, (link suspension)
Front Brake	Single 298mm disc, 2-piston caliper
Rear Brake	Single Disc, 245 mm
