Yamaha XT660R S - Pull Lever Shaft

5 - 41
ENG
PULL LEVER SHAFT
New
New
New
E
2
3
4
5
7
8
8
6
3
1
E
Order Job/Part Q’ty Remarks
Removing the pull lever shaft Remove the parts in the order listed.
1 Circlip 1
2 Circlip 1
3 Washer 2
4Pull lever 1
5 Pull lever spring 1
6 Pull lever shaft 1
7 Oil seal 1
8 Bearing 2
For installation, reverse the removal pro-
cedure.
CLUTCH
