Yamaha XT660R S Service Manual

2 - 27
SPEC
LUBRICATION POINTS AND LUBRICANT TYPES
EAS00032
CHASSIS
Lubrication Point Symbol
Front wheel oil seal lips (left and right)
LS
Rear wheel oil seal lips (left and right)
LS
Rear wheel drive hub contact surface
LS
Rear arm pivot shaft outer surface and bush outer surface and oil seal lip
LS
Dust cover thrust surface
LS
Relay arm and rear shock absorber mounting bolt outer surface
LS
Relay arm and rear shock absorber oil seal lips
LS
Relay arm and swingarm mounting bolt outer surface
LS
Relay arm and swingarm oil seal lips
LS
Relay arm and connecting arm mounting bolt outer surface
LS
Relay arm and connecting arm oil seal lips
LS
Brake pedal outer surface
LS
Rear brake master cylinder pin outer surface
LS
Steering head pipe bearings (upper and lower)
LS
Steering head pipe bearing races (upper and lower)
LS
Tube guide (throttle grip) inner surface
LS
Clutch lever pivot bolt outer surface
LS
Sidestand sliding surface and collar outer surface
LS
Footrest pivoting point
LS
Footrest spring end
LS
Chain tensioner collar (upper and lower) outer surface
LS
Rear axle shaft outer surface
LS
Passenger footrest pivoting point
LS

Yamaha XT660R S Specifications

General

Displacement	660 cc
Bore x Stroke	100.0 mm x 84.0 mm
Compression Ratio	10.0:1
Fuel System	Fuel Injection
Ignition System	TCI
Starter System	Electric
Transmission System	5-speed
Final Drive	Chain
Front Suspension System	Telescopic forks
Front Tyre	90/90-21 M/C 54S
Rear Tyre	130/80-17 M/C 65S
Overall Width	865 mm
Overall Height	1, 230 mm
Seat Height	865 mm
Wheelbase	1, 505 mm
Wet Weight	181 kg
Fuel Tank Capacity	15 litres
Oil Tank Capacity	2.9 litres
Engine Type	Liquid-cooled, 4-stroke, single cylinder, SOHC
Maximum Power	48hp (35kW) @ 6, 000rpm
Frame	Steel diamond
Rear Suspension System	Swingarm, (link suspension)
Front Brake	Single 298mm disc, 2-piston caliper
Rear Brake	Single Disc, 245 mm
