Yamaha XT660R S Service Manual

8 - 1
– +
ELEC
EAS00729
ELECTRICAL SYSTEM
ELECTRICAL COMPONENTS
1
Spark plug
2
Spark plug cap
3
Ignition coil
4
Intake air pressure sensor
5
Front brake light switch
6
Right handlebar switch
7
Immobilizer unit
8
Main switch
9
Fuel pump
0
Clutch switch
A
Left handlebar switch
B
Throttle position sensor
C
Coolant temperature sensor
D
Fuel injector
E
Lean angle cut-off switch
F
Turn signal/hazard relay
G
Headlight relay
H
Radiator fan motor relay
I
Relay unit
J
Battery
K
Fuse box 1
8
7
3
2
1
4
9
0
A
C
B
D
E
F
G
H
I
M
J
K
L
N
O
P
Q
S
R
T
U
V
W
X
[
Z
5
Y
6
ELECTRICAL COMPONENTS

Yamaha XT660R S Specifications

General

Displacement	660 cc
Bore x Stroke	100.0 mm x 84.0 mm
Compression Ratio	10.0:1
Fuel System	Fuel Injection
Ignition System	TCI
Starter System	Electric
Transmission System	5-speed
Final Drive	Chain
Front Suspension System	Telescopic forks
Front Tyre	90/90-21 M/C 54S
Rear Tyre	130/80-17 M/C 65S
Overall Width	865 mm
Overall Height	1, 230 mm
Seat Height	865 mm
Wheelbase	1, 505 mm
Wet Weight	181 kg
Fuel Tank Capacity	15 litres
Oil Tank Capacity	2.9 litres
Engine Type	Liquid-cooled, 4-stroke, single cylinder, SOHC
Maximum Power	48hp (35kW) @ 6, 000rpm
Frame	Steel diamond
Rear Suspension System	Swingarm, (link suspension)
Front Brake	Single 298mm disc, 2-piston caliper
Rear Brake	Single Disc, 245 mm
