General| Displacement | 660 cc |
|---|---|
| Bore x Stroke | 100.0 mm x 84.0 mm |
| Compression Ratio | 10.0:1 |
| Fuel System | Fuel Injection |
| Ignition System | TCI |
| Starter System | Electric |
| Transmission System | 5-speed |
| Final Drive | Chain |
| Front Suspension System | Telescopic forks |
| Front Tyre | 90/90-21 M/C 54S |
| Rear Tyre | 130/80-17 M/C 65S |
| Overall Width | 865 mm |
| Overall Height | 1, 230 mm |
| Seat Height | 865 mm |
| Wheelbase | 1, 505 mm |
| Wet Weight | 181 kg |
| Fuel Tank Capacity | 15 litres |
| Oil Tank Capacity | 2.9 litres |
| Engine Type | Liquid-cooled, 4-stroke, single cylinder, SOHC |
| Maximum Power | 48hp (35kW) @ 6, 000rpm |
| Frame | Steel diamond |
| Rear Suspension System | Swingarm, (link suspension) |
| Front Brake | Single 298mm disc, 2-piston caliper |
| Rear Brake | Single Disc, 245 mm |
