Startup Procedure and Test Run
4
4.9 Auto-Tuning
YASKAWA SIEPC71061753C GA500 Technical Manual 147
Control Tuning automatically sets the parameters in Table 4.16 to the best values.
Table 4.16 Parameters set in Control Tuning
Parameters Automatically Set Deceleration Rate Tuning KEB Tuning
C1-02 [Deceleration Time 1]
x -
C1-08 [Deceleration Time 4]
x
*1
-
C1-09 [Fast Stop Time]
- x
*2
L2-06 [Kinetic Energy Backup Decel Time]
- x
*3
L3-25 [Load Inertia Ratio]
- x
*1 The drive automatically sets C1-08 [Deceleration Time 4] only when C1-11 [Accel/Decel Time Switchover Freq] ≠ 0.
*2 When L2-29 = 0 [Kinetic Energy Backup Method = Single Drive KEB Ride-Thru 1], the drive will automatically adjust C1-09 [Fast
Stop Time] and will not adjust L2-06 [Kinetic Energy Backup Decel Time]. If you must not change the Fast Stop time, do not do KEB
Tuning.
*3 When L2-29 = 1, 2, or 3 [Kinetic Energy Backup Method = Single Drive KEB Ride-Thru 2, System KEB Ride-Thru 1, or System
KEB Ride-Thru 2], the drive will automatically adjust L2-06 [Kinetic Energy Backup Decel Time].
◆ Precautions before Auto-Tuning
Examine the topics in this section before you start Auto-Tuning.
■ Prepare for Basic Auto-Tuning
• You must input data from the motor nameplate or motor test report to do Auto-Tuning. Make sure that this data
is available before you do Auto-Tuning.
• For best performance, make sure that the drive input supply voltage is equal to or more than the motor rated
voltage.
Note:
Better performance is possible when you use a motor with a rated voltage that is less than the input supply voltage (by 20 V for 200 V
class models or by 40 V for 400 V class models). This is very important when you operate the motor at more than 90% of base speed,
where high torque precision is necessary. If the input power supply is equal to the motor rated voltage, the drive output voltage will not
be sufficient and performance will decrease.
• Push on the keypad to cancel Auto-Tuning.
• If a Safe Disable input signal is input to the drive during Auto-Tuning, Auto-Tuning measurements will not
complete successfully. If this occurs, cancel the Auto-Tuning, then do it again.
• Table 4.17 shows the status of multi-function input/output terminals during Auto-Tuning.
Table 4.17 Status of Input/Output Terminals during Auto-Tuning
Auto-Tuning Type Mode Parameter Multi-Function Input Multi-Function Output
*1
Induction Motor Auto-
Tuning
Rotational Rotational Auto-Tuning T1-01 = 0 Disabled
Functions the same as during
usual operation.
Stationary
Stationary Auto-Tuning 1 T1-01 = 1 Disabled
Keeps the status at the start of
Auto-Tuning.
Line-to-Line Resistance T1-01 = 2 Disabled
Keeps the status at the start of
Auto-Tuning.
PM Motor Auto-Tuning
Rotational PM Rotational Auto-tuning T2-01 = 4 Disabled
Functions the same as during
usual operation.
Stationary
PM Motor Parameter Settings T2-01 = 0 Disabled
Keeps the status at the start of
Auto-Tuning.
PM Stationary Auto-Tuning T2-01 = 1 Disabled
Keeps the status at the start of
Auto-Tuning.
PM Stationary Auto-Tuning for
Stator Resistance
T2-01 = 2 Disabled
Keeps the status at the start of
Auto-Tuning.
High Frequency Injection T2-01 = 5 Disabled
Keeps the status at the start of
Auto-Tuning.
EZ Tuning Stationary
Motor Parameter Setting T4-01 = 0 Disabled
Keeps the status at the start of
Auto-Tuning.
Line-to-Line Resistance T4-01 = 1 Disabled
Keeps the status at the start of
Auto-Tuning.
ASR and Inertia Tuning Rotational
Deceleration Rate Tuning T3-00 = 2 Disabled
Functions the same as during
usual operation.
KEB Tuning T3-00 = 3 Disabled
Functions the same as during
usual operation.
*1 When you set a terminal to H2-xx = E [MFDO Function Selection = Fault], it will function the same as during usual operation.
