2.8 Install the Keypad in a Control Panel or Another Device
46 YASKAWA SIEPC71061753C GA500 Technical Manual
2.8 Install the Keypad in a Control Panel or Another Device
◆ Operate the Keypad from a Remote Location
You can remove the keypad from the drive and connect it to a remote control extension cable 3 m (9.8 ft) long to
make operation easier when you cannot access the drive. It is not necessary to open or close the panel door to
operate a drive that is in a control panel. To order optional accessories, contact Yaskawa or your nearest sales
representative.
Name Option Model Intended Use
Keypad Remote Cable
WV001: 1 m (3.3 ft)
WV003: 3 m (9.8 ft)
To connect the keypad and drive.
This option is an RJ-45, 8-pin straight-through UTP CAT5e cable.
Installation Support Set A 900-192-933-001
To attach the keypad to the control panel. This option uses screws.
Installation Support Set B 900-192-933-002
To attach the keypad to the control panel. This option uses nut clamps.
Use this option when there are weld studs in the control panel.
Keypad Panel Mounting Kit ZPBA-GA500
To install the GA500 standard keypad to a control panel.
To Next Page
