Mechanical Installation
2
2.10 Conditions
YASKAWA SIEPC71061753C GA500 Technical Manual 53
Table 2.32 Three-Phase 200 V Class (Finless-Type Drive)
Drive Model
Rated Output Current
(A)
Carrier Frequency
(kHz)
Drive Watt Loss (W)
Interior Unit Loss
Heatsink Plate Loss
(P
Loss
)
Total Loss
2001 1.2 2 7 5 12
2002 1.9 2 9 9 18
2004 3.5 2 11 16 27
2006 6 2 14 25 39
2008 8 2 18 37 55
2010 9.6 2 25 51 76
2012 12.2 2 30 61 91
2018 17.5 2 35 82 117
2021 21 2 52 111 163
2030 30 2
59 175 234
2042 42 2
101 250 351
2056 56 2
127 357 484
2070 70 2
202 455 657
Table 2.33 Three-Phase 400 V Class (Finless-Type Drive)
Drive Model
Rated Output Current
(A)
Carrier Frequency
(kHz)
Drive Watt Loss (W)
Interior Unit Loss
Heatsink Plate Loss
(P
Loss
)
Total Loss
4001 1.2 2 8 7 15
4002 2.1 2 13 12 25
4004 4.1 2 14 24 38
4005 5.4 2 16 32 48
4007 7.1 2 20 44 64
4009 8.9 2 28 58 86
4012 11.9 2 39 83 122
4018 17.5 2
58 146 203
4023 23.4 2
81 204 286
4031 31 2
99 259 357
4038 38 2
141 319 460
◆ Screw Sizes and Tightening Torques
Table 2.34 shows the correct screw sizes and tightening torques to safety the drive to a metal surface (enclosure
panel).
Table 2.34 Screw Sizes and Tightening Torques
Drive Model Screw Size
Tightening Torque
N∙m (lbf∙in)
B001 - B012 M5
2.0 - 2.5
(17.7 - 22.1)
2001 - 2021 M5
2.0 - 2.5
(17.7 - 22.1)
2030 - 2056 M5
2.0 - 2.5
(17.7 - 22.1)
2070 M6
4.0 - 5.0
(35.4 - 44.3)
4001 - 4012 M5
2.0 - 2.5
(17.7 - 22.1)
4018 - 4038 M5
2.0 - 2.5
(17.7 - 22.1)
