12.11 o: Keypad-Related Settings
764 YASKAWA SIEPC71061753C GA500 Technical Manual
• E2-11 [Motor Rated Power]
• E4-11 [Motor 2 Rated Power]
• E5-02 [PM Motor Rated Power]
• E9-07 [Motor Rated Power]
• T1-02 [Motor Rated Power]
• T2-04 [PM Motor Rated Power]
• T4-08 [Motor Rated Capacity]
0 : kW
Shows the motor output in kW units.
1 : HP
Shows the motor output in HP units.
◆ o2: Keypad Operation
■ o2-01: LO/RE Key Function Selection
No.
(Hex.)
Name Description
Default
(Range)
o2-01
(0505)
LO/RE Key Function
Selection
Sets the function that lets you use to switch between LOCAL and REMOTE Modes.
1
(0, 1)
0 : Disabled
You cannot use to switch between LOCAL and REMOTE Modes.
1 : Enabled
You can use to switch between LOCAL and REMOTE Modes when the drive is stopped. When LOCAL
Mode is selected, on the keypad will come on.
WARNING! Sudden Movement Hazard. If you change the control source when b1-07 = 1 [LOCAL/REMOTE Run Selection =
Accept Existing RUN Command], the drive can start suddenly. Before you change the control source, remove all personnel from
the area around the drive, motor, and load. Sudden starts can cause serious injury or death.
WARNING! Sudden Movement Hazard. Fully examine all mechanical and electrical connections before you change o2-01 [LO/
RE Key Function Selection] or b1-07 [LOCAL/REMOTE Run Selection]. Sudden starts can cause serious injury or death. If b1-
07 = 1 [Accept Existing RUN Command] and there is an active Run command when you switch from LOCAL to REMOTE Mode,
the drive can start suddenly.
Table 12.73 Function Settings with o2-01 and b1-07
Function Selection
LOCAL/REMOTE Run Selection
Switching from LOCAL Mode to
REMOTE Mode
Switching from REMOTE Mode to
LOCAL Mode
o2-01 = 0 [Disabled] b1-07 = 0 [Disregard Existing RUN
Command]
The drive will not switch modes. The drive will not switch modes.
b1-07 = 1 [Accept Existing RUN
Command]
o2-01 = 1 [Enabled] b1-07 = 0 [Disregard Existing RUN
Command]
The drive will not start operating although
the Run command is active. When you set
Run command to active again, the drive
will start to run.
The drive cannot operate because the Run
command is not enabled.
b1-07 = 1 [Accept Existing RUN
Command]
When the Run command is active, the
drive will start to run immediately when
the mode switches from LOCAL to
REMOTE.
The drive cannot operate because the Run
command is not enabled.
■ o2-02: STOP Key Function Selection
No.
(Hex.)
Name Description
Default
(Setting Range)
o2-02
(0506)
STOP Key Function
Selection
Sets the function to use on the keypad to stop the drive when the Run command source
for the drive is REMOTE (external) and not assigned to the keypad.
1
(0, 1)
0 : Disabled
1 : Enabled
stays enabled when the Run command source has not been assigned to the keypad.
