YASKAWA CIPR-GA50CB001 Technical Manual

11.21 Defaults by Drive Model and Duty Rating ND/HD
468 YASKAWA SIEPC71061753C GA500 Technical Manual
No.
*1
Name Unit Default
- Drive Model - B010 B012 B018
C6-01
Normal / Heavy
Duty Selection
-
HD ND HD ND HD ND
0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 34 35 37
E2-11
(E4-11, E5-02)
Motor Rated
Power
kW 1.5 2.2 2.2 3.0 3.7 5.5
E2-10
(E4-10)
Motor Iron Loss W 53 77 77 91 112 172
E5-01
PM Motor Code
Selection
- FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
Power Loss Ride
Through Time
s 0.3 0.3 0.5 0.5 1 1
L2-03
Minimum
Baseblock Time
s 0.4 0.5 0.5 0.5 0.6 0.7
L2-04
Powerloss V/f
Recovery Ramp
Time
s 0.3 0.3 0.3 0.3 0.3 0.3
L2-05
Undervoltage
Detection Lvl
(Uv1)
- 160 160 160 160 160 160
L3-02
Stall Prevent
Level during
Accel
% 150 120 150 120 150 120
L3-06
Stall Prevent
Level during Run
% 150 120 150 120 150 120
L3-24
Motor Accel
Time @ Rated
Torque
s 0.166 0.145 0.145 0.145 0.154 0.168
L8-02
Overheat Alarm
Level
°C 105 105 110 110 115 115
L8-09
Output Ground
Fault Detection
- 0 0 0 0 0 0
n1-03
Hunting
Prevention Time
Constant
ms 10 10 10 10 10 10
n3-02
HSB Current
Limit Level
% 150 120 150 120 150 120
n5-02
Motor Inertia
Acceleration
Time
s 0.166 0.145 0.145 0.145 0.154 0.168
*1 Parameters within parentheses are for motor 2.
◆ Three-Phase 200 V Class
No.
*1
Name Unit Default
- Drive Model - 2001 2002 2004 2006
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 60 61 62 63
E2-11
(E4-11, E5-
02)
Motor Rated
Power
kW 0.1 0.2 0.2 0.4 0.4 0.75 0.75 1.1
b3-04
V/f Gain
during Speed
Search
% 100 100 100 100 100 100 100 100
b3-06
Speed
Estimation
Current Level
1
- 1 1 1 1 1 1 0.5 0.5
b3-08
Speed
Estimation
ACR P Gain
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
