1 Outline
1.1.1 Check Items
1-2
1.1 Checking Products
The following procedure is used to check the AC servo drives of Σ-ΙΙ Series products on delivery.
1.1.1 Check Items
Check the following items when Σ-ΙΙ Series products are delivered.
If any of the above items are faulty or incorrect, contact your Yaskawa representative or the dealer from whom
you purchased the products.
1.1.2 Servomotors
1.1.3 SERVOPACKs
Check Items Comments
Are the delivered products the ones
that were ordered?
Check the model numbers marked on the nameplates on the servomo-
tor and SERVOPACK. (Refer to the descriptions of model numbers in
the following section.)
Does the servomotor shaft rotate
smoothly?
The servomotor shaft is normal if it can be turned smoothly by hand.
Servomotors with brakes, however, cannot be turned manually.
Is there any damage? Check the overall appearance, and check for damage or scratches that
may have occurred during shipping.
Manufacturing date
Serial number
Servomotor model
Rated output
Rated rotation speed
SGMVH
servomotor
AC SERVO MOTOR
TYPE
SGMVH - 2BDCA
kw N
.
m
min
SER.NO.
A
RATING
DATE
22
140
1500
58
CONT.
K7A500 101 - 004
9708
ENCODER
UTMAH-B12BDYR11
17 bit
YASKAWA ELECTRIC CORPORATION
JAPAN
-1
Σ-II Series SGDM and SGDH
SERVOPACKs
SERVOPACK model
Serial number
Output power
Applicable power supply
SERVOPACK
SGDH - 3ZDEB
AC- INPUT AC- OUTPUT
MODEL
VOLTS 380 - 480
Hz 50/60
PHASE 3
AMPS 145
VOLTS 0 - 480
PHASE 3
AMPS 175
30.0 (40.2)
S / N R7C303 - 221 - 4
YASKAWA ELECTRIC
MADE IN JAPAN
kW (HP)
+2-+1
L1/R L2/S
L3/T
UVW
480
V
460
V
DU
400
V
0
V
440
V
DWDV B1
380
V
DC
24N
B2
DC
24P
CHARGE
S-HDG
㧖㧖㧖㧖
T DATA/SEEMOD/
KSERVOPAC
AYASKAW
R
O
P
E
R
A
T
O
CN3
8CN
POWER
CN5
WARNING
ෂޓ㒾
ㅢ㔚߮㔚Ḯࠝࡈᓟ5
ಽ㑆ޔ┵ሶㇱߦ⸅ࠆߥ!
electric shock.
Disconnect all power
May cause
ᗵ㔚ߩᕟࠇࠅ
before servicing.
and wait 5 min.
grounding techniques.
ធ⛯ߖࠃ
Use proper
ᔅߕࠕ㧙ࠬ✢ࠍ
