YASKAWA E-II Series User Manual

2 Selections
2.5.2 Molded-case Circuit Breaker and Fuse Capacity
2-8
2.5.2 Molded-case Circuit Breaker and Fuse Capacity
Select a input fuse or molded-case circuit breaker that comply with UL standard.
* 1. Nominal value at the rated load.
* 2. Cutoff characteristics (25
°C): 200% for two seconds min. and 700% for 0.01 seconds min.
* 3. The values will vary, depending on the 24 VDC control power supply used.
Note: Do not use a fast-acting fuse. Because the SERVOPACK’s power supply is a capacitor
input type, a fast-acting fuse may blow when the power is turned ON.
SERVOPACK Model
Power Supply
Capacity per
SERVOPACK
(kVA)
∗1
Current Capacity of the
Molded-case Circuit Breaker
and the Fuse (A)
∗2
Inrush Current (A)
Main Circuit
Power Supply
Control Circuit
Power Supply
SGDM-2BADB
SGDH-2BAEB
36.7 150 300 30
SGDM-3ZADB
SGDH-3ZAEB
50.1 200 300 30
SGDM-3GADB
SGDH-3GAEB
61.8 225 600 30
SGDH-2BDEB
36.7 100 140
(10)
*3
SGDH-3ZDEB
50.1 150 565
SGDH-3GDEB
61.8 150 565
SGDH-4EDEB
75.2 225 1130
SGDH-5EDEB
91.9 225 1130
SGDH-9ZDEB
125.3 300 170
