YASKAWA E-II Series User Manual

4 SERVOPACK Specifications and Dimensional Drawings
4.1.1 Three-phase 200 V
4-2
4.1 SERVOPACK Ratings and Specifications
4.1.1 Three-phase 200 V
The value of the input power supply voltage is maximum 253 Vrms.
4.1.2 Three-phase 400 V
The value of the input power supply voltage is maximum 528 Vrms.
• Take appropriate measures to ensure that the input power supply is supplied within the specified voltage
range.
An incorrect input power supply may result in damage to the SERVOPACK. If the voltage exceeds these values, use
a step-down transformer so that the voltage will be within the specified range.
CAUTION
SERVOPACK
Model
SGDM- 2BADB 3ZADB 3GADB
SGDH- 2BAEB 3ZAEB 3GAEB
Max. Applicable Servomotor Capacity (kW)
22 30 37
Continuous Output Current (Arms)
110 148 195
Max. Output Current (Arms)
240 340 460
Input Power Supply Main Circuit Three-phase 200 to 230 VAC +10% to -15%, 50/60 Hz
Control Circuit Single-phase 200 to 220 VAC +10% to -15%, 50 Hz
Single-phase 200 to 230 VAC +10% to -15%, 60 Hz
Configuration Base-mounted
SERVOPACK Model SGDH- 2BDEB 3ZDEB 3GDEB 4EDEB 5EDEB 9ZDEB
Max. Applicable Servomotor Capacity (kW)
22 30 37 45 55 75
Continuous Output Current (Arms)
52.2 75 98 127 150 210
Max. Output Current (Arms)
120 170 230 280 340 580
Input Power Supply Main Circuit Three-phase 380 to 480 VAC +10% to -15%, 50/60 Hz
Control Circuit 24 VDC ±15%
For Control Actuator Single-phase 380 to 480 VAC, 50/60 Hz, 150 VA
Configuration Base-mounted
