YASKAWA E-II Series User Manual

5 Specifications and Dimensional Drawings of Cables and Peripheral Devices
5.1.3 Three-phase 400 V
5-4
5.1.3 Three-phase 400 V
SERVOPACK
Model
SGDH-

DEB
Terminal Symbol
Terminal
Screw Size
Tightening Torque
Nxm
Applicable Cable
Range
mm
2
(AWG)
Recommended
Cable Size
mm
2
(AWG)
2B
L1/R, L2/S, L3/T
-, +1, +2
M8 9.0 to 11.0
14 to 38
(6 to 2)
14
(6)
U, V, W M8 9.0 to 11.0
14 to 38
(6 to 2)
14
(6)
DC24P, DC24N M4 1.2 to 1.5
0.75 to 2
(18 to 14)
1.25
(16)
B1, B2 M4 1.2 to 1.5
2 to 5.5
(14 to 10)
5.5
(10)
0 V, 380 V, 400 V
440 V, 460 V, 480 V
M3.5 0.8 to 0.88
0.75 to 2
(18 to 14)
1.25
(16)
DU, DV, DW M4 1.2 to 1.5
2 to 5.5
(14 to 10)
2
(14)
M8 9.0 to 11.0
14 to 38
(6 to 2)
14
(6)
3Z
L1/R, L2/S, L3/T
-, +1, +2
M8 9.0 to 11.0
14 to 38
(6 to 2)
14
(6)
U, V, W M8 9.0 to 11.0
14 to 38
(6 to 2)
22
(4)
DC24P, DC24N M4 1.2 to 1.5
0.75 to 2
(18 to 14)
1.25
(16)
B1, B2 M5 2.0 to 2.5
8 to 14
(8 to 6)
8
(8)
0 V, 380 V, 400 V
440 V, 460 V, 480 V
M3.5 0.8 to 0.88
0.75 to 2
(18 to 14)
1.25
(16)
DU, DV, DW M4 1.2 to 1.5
2 to 5.5
(14 to 10)
2
(14)
M8 9.0 to 11.0
22 to 38
(4 to 2)
22
(4)
3G
L1/R, L2/S, L3/T
-, +1, +2
M10 17.5 to 20.5
22 to 80
(4 to 3/0)
22
(4)
U, V, W M10 17.5 to 20.5
30 to 80
(3 to 3/0)
30
(3)
DC24P, DC24N M4 1.2 to 1.5
0.75 to 2
(18 to 14)
1.25
(16)
B1, B2 M5 2.0 to 2.5
8 to 14
(8 to 6)
8
(8
)
0 V,
380 V, 400 V
440 V, 460 V, 480 V
M3.5 0.8 to 0.88
0.75 to 2
(18 to 14)
1.25
(16)
DU, DV, DW M5 1.2 to 1.5
0.75 to 5.5
(18 to 10)
3.5
(12)
DBON, DB24 M3.5 0.8 to 0.88
0.75 to 2
(18 to 14)
1.25
(16)
M8 9.0 to 11.0
30 to 38
(3 to 2)
30
(3)
