YASKAWA E-II Series User Manual

2 Selections
2.5.5 Dynamic Brake (DB) Units
2-10
2.5.5 Dynamic Brake (DB) Units
Externally attach a dynamic brake resistor to the SERVOPACK to dissipate regenerative energy when using the
dynamic brake function. The dynamic brake resistor does not need to be installed if the dynamic brake function is
not required.
Use the dynamic brake unit under the following conditions. Contact your Yaskawa representative before using
the unit under conditions more severe than those specified below.
• Allowable load moment of inertia: 5 times the load moment of inertia
• Allowable duty: Less than one DB stop per hour at maximum rotation speed
Dynamic Brake
(DB) Unit Model
SERVOPACK Model Resistance
Specifications
(Star Wiring )
DB Contactor and
Surge Absorption Unit
SGDM- SGDH-
JUSP–DB01
2BADB, 3ZADB 2BAEB, 3ZAEB 180 W, 0.3 Ω
Built into the
SERVOPACK
JUSP–DB02
3GADB 3GAEB 180 W, 0.3 Ω
Built into Dynamic Brake
Unit
JUSP–DB03
−
2BDEB, 3ZDEB 180 W, 0.8 Ω
Built into the
SERVOPACK
JUSP–DB04
−
3GDEB 180 W, 0.8 Ω
Built into Dynamic Brake
Unit
JUSP–DB05
−
4EDEB 180 W, 0.8 Ω
Built into Dynamic Brake
Unit
JUSP–DB06
−
5EDEB 300 W, 0.8 Ω
Built into Dynamic Brake
Unit
JUSP–DB12
−
9ZDEB 600 W, 0.9 Ω
Built into Dynamic Brake
Unit
