4.4 SERVOPACK’s Power Supply Capacities and Power Losses
4
SERVOPACK Specifications and Dimensional Drawings
4-11
4.4 SERVOPACK’s Power Supply Capacities and Power Losses
The following table shows SERVOPACK’s power supply capacities and power losses at the rated output.
Main Circuit Power
Supply
SERVOPACK
Model
Output
Current
(Effective
Value)
A
Main Circuit
Power Loss
W
Control
Circuit
Power
Loss
W
To ta l
Power
Loss
W
Three-phase 200 VAC SGDM-2BADB
110 670
72
742
SGDM-3ZADB
148 980 1052
SGDM-3GADB
195 1700 120 1820
SGDH-2BAEB
110 670
72
742
SGDH-3ZAEB
148 980 1052
SGDH-3GAEB
195 1700 120 1820
Three-phase 400 VAC SGDH-2BDEB
52.2 650
120
770
SGDH-3ZDEB
72 970 1090
SGDH-3GDEB
90 1140 1260
SGDH-4EDEB
127 1440 1560
SGDH-5EDEB
150 1720 1840
SGDH-9ZDEB
210 2500 2620
