YASKAWA E-II Series User Manual

5.5 Peripheral Devices
5
Specifications and Dimensional Drawings of Cables and Peripheral Devices
5-15
5.5.3 Cables for Analog Monitor
(1) Cable Type: JZSP-CA01 (DE9404559)
Connect the specified cables to CN5 connector for monitoring the analog monitor signals. For details, refer to
9.5 Analog Monitor.
Note: Specify the cable type either JZSP-CA01 or DE9404559 when ordering the cable for analog moni-
tor.
(2) Dimensional Drawing
* Manufactured by Hirose Electric Corporation.
(3) Specifications
Note: The above monitoring items are the factory settings. The monitoring items can be changed by set-
ting the parameter Pn003. Refer to 9.5 Analog Monitor.
Cable for Analog Monitor

.4 .5
.6
789

8

8
&7

8

8

8
&9&8 $

8
&%
0
$
&%
2
%*#4)'
5*&) 㧖㧖㧖㧖
6 &#6#5''/1& 
-5'4812#%
#;#5-#9
4
1
2
'
4
#
6
1
%0
%0
219'4
%0
WARNING
ෂޓ㒾
ㅢ㔚෸߮㔚Ḯࠝࡈᓟ5
ಽ㑆ޔ┵ሶㇱߦ⸅ࠆߥ
electric shock.
Disconnect all power
May cause
ᗵ㔚ߩᕟࠇ޽ࠅ
before servicing.
and wait 5 min.
grounding techniques.
ធ⛯ߖࠃ
Use proper
ᔅߕࠕ㧙ࠬ✢ࠍ
3
4
1
2
Socket: DF11-4DS-2C
∗
Connector: DF11-2428SCF
∗
1000 ޓmm
-0
+20
White
Red
Black
Black
Viewed from the cable
Pin No. Cable Color Signal Monitoring Item
1
Red
Analog Monitor 2
Motor speed: 1V/1000 min
-1
2
White
Analog Monitor 1 Torque reference: 1V/100% rated torque
3 and 4
Black (2 cables)
GND (0 V) −
