YASKAWA E-II Series User Manual

2.5 Selecting Peripheral Devices
2
Selections
2-9
2.5.3 Noise Filters, Magnetic Contactors, and Brake Power Supply Units
Note: 1. If some SERVOPACKs are wired at the same time, select the proper magnetic contactors accord-
ing to the total capacity.
2. The following table shows the manufacturers of each device.
2.5.4 Regenerative Resistor Units
SERVOPACK Model Recommended Noise Filter Magnetic Contactor Brake Power Supply Unit
SGDM-2BADB
SGDH-2BAEB
FN258L-130-35 SC-N6 (125A)
c24 VDC brake (provided by a
customer)
d90 VDC brake
• LPDE-1H01 for 100 VAC input
• LPSE-2H01 for 200 VAC input
SGDM-3ZADB
SGDH-3ZAEB
FN258L-180-07 SC-N8 (180A)
SGDM-3GADB
SGDH-3GAEB
FN359P-250-99 SC-N10 (220A)
SGDH-2BDEB
FN258L-180-07 SC-N6 (125A)
SGDH-3ZDEB
FN258L-180-07 SC-N8 (180A)
SGDH-3GDEB
FN258L-180-07 SC-N8 (180A)
SGDH-4EDEB
FN359P-250-99 SC-N10 (220A)
SGDH-5EDEB
FN359P-250-99 SC-N10 (220A)
SGDH-9ZDEB
FN359P-300-99 SC-N11 (300A)
Peripheral Device Manufacturer
Noise Filter Schaffner Electronic
Magnetic Contactor Fuji Electric Co., Ltd.
Brake Power Supply
Unit
Yaskawa Controls Co., Ltd.
SERVOPACK
Model
SGDM- 2BADB 3ZADB 3GADB −
SGDH- 2BAEB 3ZAEB 3GAEB 2BDEB 3ZDEB 3GDEB 4EDEB 5EDEB 9ZDEB
Regenerative
Resistor Unit
Model
JUSP-
RA08 RA09 RA11 RA12 RA13 RA14 RA15 RA16 RA25
Resistance (Ω)
2.4 1.8 1.6 9 6.7 5 4 3.8 2.1
Resistance
Capacity (W)
2400 4800 4800 3600 3600 4800 6000 7200 16800
Allowable Load Moment of
Inertia (×10
-4
kg·m
2
)
1830 2490 2875 1830 2490 2875 5355 6450 9020
Allowable Duty 2% ED at maximum speed and torque deceleration.
