Input Terminal Functions
6-51
Input Terminal Functions
Temporarily Switching Operation between Digital Operator
and Control Circuit Terminals
You can switch the Inverter run command inputs and frequency reference inputs between local (i.e., Digital
Operator) and remote (input method set in b1-01 and b1-02).
If any input from H1-01 to H1-05 (multi-function contact input terminal S3 to S7 function selection) has been
set to 1 (local/remote selection), this input can be used to switch over between local and remote.
To set the frequency reference source and RUN command source to control circuit terminals, set b1-01 and
b1-02 to 1.
Related Constants
Con-
stant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
b1-01 Reference selection
Sets the frequency reference input method.
0: Digital Operator
1: Control circuit terminal (analog input)
2: MEMOBUS communications
3: Option Card
0 to 3 1 No Q
b1-02 RUN command source selection
Sets the run command input method
0: Digital Operator
1: Control circuit terminal (digital multifunction inputs)
2: MEMOBUS communications
3: Option Card
0 to 3 1 No Q
You can also perform local/remote switching using the LOCAL/REMOTE key on the Digital Operator. When
the local/remote function has been set for one external terminal, the LOCAL/REMOTE key function on the
Digital Operator will be disabled.
INFO
