6-102
Digital Operator Functions
Setting Digital Operator Functions
Related Constants
Con-
stant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
o1-01 Monitor selection
Set the number of the 3rd. monitor item to be displayed in
the Drive Mode. (U1-)
(Not on LCD operator JVOP-160.)
4 to 33 6 Yes A
o1-02 Monitor selection after power up
Set the monitor item to be displayed when the power sup-
ply is turned ON.
1: Frequency reference
2: Output frequency
3: Output current
4: The monitor item set for o1-01
1 to 4 1 Yes A
o1-03
Frequency units of reference set-
ting and monitor
Sets the units that will be set and displayed for the fre-
quency reference and frequency monitor.
0: 0.01 Hz units
1: 0.01% (Maximum output frequency is
100%)
2 to 39: rotation per minute (rpm) (Sets the motor
poles)
40 to 39999: User desired display
Set the desired values for setting and dis-
play for the max. output frequency.
Example: When the max. output frequency value is 200.0,
set 12000.
0 to
39999
0NoA
o2-01
LOCAL/REMOTE key
enable/disable
Set the run method selection key (LOCAL/REMOTE key)
function.
0: Disabled
1: Enabled (Switches between the Digital Operator and
the constant settings.)
0 or 1 1 No A
o2-02
STOP key during control circuit
terminal operation
Set the STOP key in the run mode.
0: Disabled (When the run command is issued from an
external terminal, the Stop key is disabled.)
1: Enabled (Effective even during run.)
0 or 1 1 No A
o2-03 User constant initial value
Clears or stores user initial values.
0: Stores/not set
1: Begins storing (Records the set constants as user initial
values.)
2: All clear (Clears all recorded user initial values)
When the set constants are recorded as user initial values,
1110 will be set in A1-03.
0 to 2 0 No A
o2-05
Frequency reference setting
method selection
When the frequency reference is set on the Digital Opera-
tor frequency reference monitor, sets whether the Enter
key is necessary or not.
0: Enter key needed
1: Enter key not needed
When set to 1, the Inverter accepts the frequency reference
without Enter key operation.
0 or 1 0 No A
o2-06
Operation selection when digital
operator is disconnected
Sets the operation when the Digital Operator is discon-
nected.
0: Disabled (Operation continues even if the Digital
Operator is disconnected.)
1: Enabled (OPR is detected at Digital Operator
disconnection. Inverter output is switched off, and fault
contact is operated.)
0 or 1 0 No A
o2-07 Cumulative operation time setting
Sets the cumulative operation time in hour units.
Operation time is calculated from the set values.
0 to
65535
0NoA
Set digit number excluding
the decimal point.
Set the number of digits
below the decimal point to
display.
