Wiring the Main Circuits
This section describes wiring connections for the main circuit inputs and outputs.
Wiring Main Circuit Inputs
Observe the following precautions for the main circuit power supply input.
Installing Fuses
To protect the inverter, it is recommended to use semiconductor fuses like they are shown in the table below.
Table 2.6 Input Fuses
Inverter Type FUSE
Voltage (V) Current (A)
I
2
t (A
2
s)
20P4 240 10 12~25
20P7 240 10 12~25
21P5 240 15 23~55
22P2 240 20 34~98
23P7 240 30 82~220
25P5 240 40 220~610
27P5 240 60 290~1300
2011 240 80 450~5000
2015 240 100 1200~7200
2018 240 130 1800~7200
2022 240 150 870~16200
2030 240 180 1500~23000
2037 240 240 2100~19000
2045 240 300 2700~55000
2055 240 350 4000~55000
2075 240 450 7100~64000
2090 240 550 11000~64000
2110 240 600 13000~83000
40P4 480 5 6~55
40P7 480 5 6~55
41P5 480 10 10~55
42P2 480 10 18~55
43P7 480 15 34~72
44P0 480 20 50~570
45P5 480 25 100~570
47P5 480 30 100~640
4011 480 50 150~1300
4015 480 60 400~1800
4018 480 70 700~4100
4022 480 80 240~5800
4030 480 100 500~5800
4037 480 125 750~5800
4045 480 150 920~13000
4055 480 150 1500~13000
4075 480 250 3000~55000
4090 480 300 3800~55000
4110 480 350 5400~23000
4132 480 400 7900~64000
4160 480 450 14000~250000
4185 480 600 20000~250000
4220 480 700 34000~400000
4300 480 900 52000~920000
