 Control Circuit Terminal Connections
Connections to Inverter control circuit terminals are shown in Fig 2.14.
Fig 2.14 Control Circuit Terminal Connections
M2
M1
Contact output 1
(Default : Running)
M4
M3
Contact output 2
(Default : Zero speed)
MC
MB
Fault contact output
250 VAC, 1A max.
30 VDC, 1A max.
MA
Multi-function contact
output
250 VAC, 1A max.
30 VDC, 1A max.
Varispeed E7
CIMR-
E7C47P5
Forward Run/Stop S1
Reverse Run/Stop S2
S3External fault
S4
Fault reset
S5
Multi-step speed setting 1
S6
S7
SN
Multi-step speed setting 2
Jog frequency selection
SC
SP
24V
Multi-function
contact inputs
(Factory setting)
+V
AC
A2
Multifunction Analog Input 2
[Default: Frequency Bias
4 to 20mA (250 ohm)]
Analog Input 1
Master speed reference
0 to +10V (20k ohm)
A1
0V
Frequency setting power
+15V, 20mA
E(G)
Shield
terminal
PP
4 to 20mA
0 to 10V
2k ohm
Analog input
adjustment
3
2k ohm
E(G)
FM
+
-
A
M
+
-
A
C
A
M
FM
A
djustment
A
djustment
Multi-function analogue output 1
(0 to +10V 2mA)
[Default: Output frequency]
Multi-function analogue output 2
(0 to +10V 2mA)
[Default: Output current]
Shield
terminal
R+
R-
S+
S-
IG
Ter mi na ti ng
resistance
Shielded wires P
Twisted-pair
Shielded wires
MEMOBUS
communication
RS-485/422
P
P
2
1
-V
