YASKAWA Varispeed E7 User Manual

1-2
Varispeed E7 Introduction


 Varispeed E7 Applications
The Varispeed E7 is ideal for the following applications.
• Fan, blower, and pump applications
Settings must be adjusted to the application for optimum operation. Refer to Chapter 4 Trial Operation.


 Varispeed E7 Models
The Varispeed E7 Series includes Inverters in two voltage classes: 200 V and 400 V. The maximum motor capacities
vary from 0.55 to 300 kW (42 models).
Table 1.1 Varispeed E7 Models
Voltage
Class
Maximum
Motor
Capacity
kW
Var isp ee d E 7
Specifications
(Always specify through the protective structure when ordering.)
Output
Capacity
kVA
Basic Model Number
Open Chassis
(IEC IP00)
CIMR-E7C
Enclosed Wall-mounted
(IEC IP20, NEMA 1)
CIMR-E7C
200 V class
0.55 1.2 CIMR-E7C20P4
Remove the top and bottom cov-
ers from the Enclosed Wall-
mounted model.
20P41
0.75 1.6 CIMR-E7C20P7 20P71
1.5 2.7 CIMR-E7C21P5 21P51
2.2 3.7 CIMR-E7C22P2 22P21
3.7 5.7 CIMR-E7C23P7 23P71
5.5 8.8 CIMR-E7C25P5 25P51
7.5 12 CIMR-E7C27P5 27P51
11 17 CIMR-E7C2011 20111
15 22 CIMR-E7C2015 20151
18.5 27 CIMR-E7C2018 20181
22 32 CIMR-E7C2022 20220 20221
30 44 CIMR-E7C2030 20300 20301
37 55 CIMR-E7C2037 20370 20371
45 69 CIMR-E7C2045 20450 20451
55 82 CIMR-E7C2055 20550 20551
75 110 CIMR-E7C2075 20750 20751
90 130 CIMR-E7C2090 20900 –
110 160 CIMR-E7C2110 21100 –
