1-6
Component Names
Inverters of 18.5 kW or Less
The external appearance and component names of the Inverter are shown in Fig 1.4. The Inverter with the ter-
minal cover removed is shown in Fig 1.5.
Fig 1.4 Inverter Appearance (18.5 kW or Less)
Fig 1.5 Terminal Arrangement (18.5 kW or Less)
Top protective cover (Part of Enclosed Wall-
mounted Type (IEC IP20, NEMA Type 1)
Front cover
Digital Operator
Terminal cover
Bottom protective cover
Diecast case
Nameplate
Mounting hole
Charge indicator
Ground terminal
Control circuit terminals
Main circuit terminals
