2-26
Wiring Check
Checks
Check all wiring after wiring has been completed. Do not perform continuity check on control circuits. Per-
form the following checks on the wiring.
• Is all wiring correct?
• Have no wire clippings, screws, or other foreign material been left?
• Are all screws tight?
• Are any wire ends contacting other terminals?
