1-8
Exterior and Mounting Dimensions
Open Chassis Inverters (IP00)
Exterior diagrams of the Open Chassis Inverters are shown below.
Fig 1.8 Exterior Diagrams of Open Chassis Inverters
200 V Class Inverters of 22 or 110 kW
400 V Class Inverters of 22 to 160 kW
200 V/400 V Class Inverters of 0.55 to 18.5 kW
400 V Class Inverters of 185 to 300 kW
