Digital Operation Display Functions and Levels
5-3
Digital Operation Display Functions and Levels
The following figure shows the Digital Operator display hierarchy for the Inverter.
MENU
Drive Mode
Inverter can be operated and
its status can be displayed.
Quick Programming Mode
Minimum constants required
for operation can be monitored
or set.
Advanced Programming Mode
All constants can be monitored
or set.
Verify Mode
Constants changed from the
default settings can be moni-
tored or set.
Autotuning Mode
Automatically measures the
line-to-line resistance.
No. Function Page
U1 Status Monitor Constants 5-42
U2 Fault Trace 5-45
U3 Fault History 5-46
A1 Initialize Mode 5-10
A2 User-specified Setting Mode 5-11
b1 Operation Mode Selections 5-12
b2 DC Injection Braking 5-13
b3 Speed Search 5-14
b4 Timer Function 5-15
b5 PI Control 5-15
b8 Energy Saving 5-17
C1 Acceleration/Deceleration 5-18
C2 S-curve Acceleration 5-18
C4 Torque Compensation 5-19
C6 Carrier Frequency 5-20
d1 Preset Reference 5-21
d2 Reference Limits 5-21
d3 Jump Frequencies 5-22
d4 Reference Frequency Hold 5-22
E1 V/f Pattern 5-23
E2 Motor Setup 5-24
F6 Communications Option Card 5-25
H1 Multi-function Digital Inputs 5-26
H2 Multi-function Digital Outputs 5-27
H3 Multi-function Analog Inputs 5-28
H4 Multi-function Analog Outputs 5-29
H5 MEMOBUS Communications 5-31
L1 Motor Overload 5-32
L2 Power Loss Ridethrough 5-33
L3 Stall Prevention 5-34
L4 Reference Detection 5-35
L5 Fault Restart 5-35
L6 Torque Detection 5-36
L8 Hardware Protection 5-37
N1 Hunting Prevention Function 5-38
N3 High-slip Braking 5-38
o1 Monitor Select 5-39
o2 Multi-function Selections 5-40
o3 Copy Function 5-41
T
Motor Autotuning
5-42
