Administrator’s Guide for SIP-T2xP IP Phones
12
2) Connecting the Handset and optional Headset:
3) Connecting the Network and Power:
You have two options for power and network connections. Select a suitable way
according to your actual situation.
AC power
Power over Ethernet (PoE)
AC Power
To connect the AC power and network:
1. Connect the DC plug of the power adapter to the DC5V port on the phone and
connect the other end of the power adapter into an electrical power outlet.
2. Connect the supplied Ethernet cable between the Internet port on the phone and
the Internet port in your network or switch/hub device port.
Power over Ethernet
Using a regular Ethernet cable, the SIP-T28P and SIP-T26P IP phones can be powered
from a PoE (IEEE 802.3af) compliant switch or hub.
