1 - 12 TC70x/TC75x Integrator Guide
Replacing the microSD Card
To replace the microSD card:
1. Press the Power button until the menu appears.
2. Touch Power off.
3. Touch OK.
4. If hand strap is attached, slide the hand strap clip up toward the top of the TC70x/TC75x and then lift.
Figure 1-24 Remove Hand Strap Clip
5. Press the two battery latches in.
6. Lift the battery from the TC70x/TC75x.
7. Lift the access door.
Figure 1-25 Remove Access Door
8. Remove microSD card from holder.
9. Press the access door down and ensure that it is properly seated.
10. Insert the replacement microSD card.
11. Replace the access door.
Figure 1-26 Replace Access Door
12. Insert the battery, bottom first, into the battery compartment in the back of the TC70x/TC75x.
