Accessories 2 - 19
Installing the Four Slot Battery Charger
1. Remove power from the cradle.
Figure 2-17 Remove Power from Cradle
2. Using a Phillips screwdriver, remove the screw securing the cup to the cradle base.
Figure 2-18 Remove Screw
3. Slide the cup to the front of the cradle.
NOTE The Battery Charger must be installed in the first slot only.
