9.1.2 Ambient conditions
The user must ensure that the specified ambient conditions are observed.
Ambient temperature for operation [°C] 0 to +40
Humidity [V] Maximum 95 / condensation not permitted
Installation height [m above
sea]
Above 1000
Torque reduction by 1 % per 100 m or
On time reduction by 1.5 % per 100 m
9.1.3 Brake
Brake type
RTW 1000
(information for each brake circuit)
Brake torque [Nm] 1200
Operating voltage [Vdc] 207
Rated output power [W] 158
Electrical protection rating IP 54
M
echanical protection rating IP 10
9.1.3.1 Micro switch
Minimum rating
[mA / V] 10 / 12
Maximum rating [A / V] 3 / 250
Recommended rating [mA / V] 10 - 50 / 24
9.1.3.2 Inductive proximity switch
Operating voltage
[VDC] 10 - 30
Rated operating current [mADC] 150
Output function NC contact / gauge zero
For further information refer to the “Appendix - Brake operating instructions - Assembly and adjust-
ment of the release monitor with inductive proximity switch” chapter.
Translation of the original operating instructions
ZAtop – model series SM210.60B/SM210.70B Enclosure
$7%$B*% ,QGH[ Part.-No. 01013389-GB (EU-BD 1014)
43/88
