Type DTS Nbn Nbmax Vn
(1:1)
Vmax
(1:1)
Vn
(2:1)
Vmax
(2:1)
SM225.60B 600 400 460 12.57 14.45 6.28 7.23
SM250.60B 320 400 460 6.70 7.71 3.35 3.85
SM250.60B 400 400 460 8.38 9.63 4.19 4.82
SM250.60B 500 400 460 10.47 12.04 5.24 6.02
SM250.60B 600 400 460 12.57 14.45 6.28 7.23
SM250.80D 440 400 460 9.22 10.60 4.61 5.30
SM250.80D 520 400 460 10.89 12.52 5.45 6.26
SM250.80D 640 400 460 13.40 15.41 6.70 7.71
SM250.100C 450 400 460 9.42 10.84 4.71 5.42
SM250.100C 500 400 460 10.47 12.04 5.24 6.02
SM250.100C 520 400 460 10.89 12.52 5.45 6.26
9.8 Calculation proof - Translation -
(english)
A-BN17_06-GB
1715 Index 001
Manufacturer:ZI
EHL-ABEGG SE
Heinz-Ziehl-Straße
74653 Künzelsau
Germany
Confirmation concerning the examination of traction sheave shaft calculation including shaft-
hub-connections.
Type of the gearless
maschine:
ZAt
op SM210.60B
Object examined: Cal
culation of traction sheave shaft including shaft-hub-connections
by IFF ENGINEERING & CONSULTING GmbH No. 7.1.508.3 vom
05.04.2017
Examination basis: DIN 743-1:2012-12 Calculation of load capacity of shafts and axles –
Part 1: General
DIN 743-2:2012-12 Calculation of load capacity of shafts and axles –
Par
t 2: Theoretical stress concentration factors and
fatigue notch factors
DIN 743-3:2012-12 Calculation of load capacity of shafts and axles –
Par
t 3: Strenght of materials
DIN 743-3
Cor
rigendum 1:2014-
12
Calculation of load capacity of shafts and axles –
Part 3: Strenght of materials,
Corrigendum to DIN 743-3:2012-12
DIN 743-4:2012-12 Calculation of load capacity of shafts and axles –
Par
t 4: Fatique limit, endurance limit – Equivalently
damaging continuous stress
DIN 6892:2012-08 Drive type fastenings without taper action –
Par
allel keys – Calculation and design
DIN 6892
Cor
rigendum 1:2014-
05
Drive type fastenings without taper action –
Parallel keys – Calculation and design,
Corrigendum to DIN 6892:2012-08
Translation of the original operating instructions
ZAtop – model series SM210.60B/SM210.70B Enclosure
$7%$B*% ,QGH[ Part.-No. 01013389-GB (EU-BD 1014)
78/88
