ZXR10 GER (V2.6.03) General Excellent Router User Manual Volume-I
326 Confidential and Proprietary Information of ZTE CORPORATION
Router Loopback Task Tunnel
R1 100.1.1.1 End
node
Tunnel1, destination address
100.1.1.3
R2 100.1.1.2 Middle
node
R3 100.1.1.3 End
node
Tunnel3, destination address
100.1.1.1
R1 configuration:
R1(config)#interface fei_1/1
R1(config-if)#ip address 10.10.12.1 255.255.255.0
R1(config-if)#ip rsvp bandwidth 30000 10000
R1(config-if)#mpls traffic-eng tunnels
R1(config-if)#exit
R1(config)#interface loopback1
R1(config-if)#ip address 100.1.1.1
255.255.255.255
R1(config-if)#exit
R1(config)#mpls traffic-eng tunnels
R1(config)#
R1(config)#router ospf 1
R1(config-router)#mpls traffic-eng area 0
R1(config-router)#mpls traffic-eng router-id
loopback1
R1(config-router)#network 100.1.1.1 0.0.0.0 area
0
R1(config-router)#network 10.10.12.1 0.0.0.255
area 0
R1(config-router)#exit
R1(config)#
R2 configuration:
R2(config)#interface fei_1/5
R2(config-if)#ip address 10.10.12.2 255.255.255.0
R2(config-if)#mpls traffic-eng tunnels
R2(config-if)#ip rsvp bandwidth 30000 10000
R2(config-if)#exit
R2(config)#
R2(config)#interface fei_1/6
R2(config-if)#ip address 10.10.23.2 255.255.255.0
R2(config-if)#mpls traffic-eng tunnels
R2(config-if)#ip rsvp bandwidth 30000 10000
R2(config-if)#exit
R2(config)#
R2(config)#interface loopback1
