ACH580 E-Clipse bypass and packaged drive user manual 95
Embedded fieldbus
Diagnostics – EFB
Fault queue for drive diagnostics (read via Drive node)
For general ACH580 diagnostics information, see the Diagnostics section on
page 185. For specific ACH580 fault codes, refer to the ACH580 Hardware Manual
(3AXD50000044839).
Fault queue for bypass diagnostics (read via Bypass node)
For general E-Clipse Bypass diagnostics information, see Diagnostics section on
page 185. For specific E-Clipse bypass fault codes, see Fault listing on page 186.
DI DI2 Status Bypass digital input 2 status BI11 BI6
DI DI3 Status Bypass digital input 3 status BI12 BI7
DI DI4 Status Bypass digital input 4 status BI13 BI8
DI DI5 Status Bypass digital input 5 status BI14 BI9
DI DI6 Status Bypass digital input 6 status BI15 BI10
DI RO1 Status Bypass relay output 1 status BI16 BI0
DI RO2 Status Bypass relay output 2 status BI17 BI1
DI RO3 Status Bypass relay output 3 status BI18 BI2
DI RO4 Status Bypass relay output 4 status BI19 BI3
DI RO5 Status Bypass relay output 5 status BI20 BI4
DI Bypass Select 1=Bypass mode, 0=Drive mode BI21 BV4
DI System Underload Reports system underload status (either mode) BI22 BV8
DI System Fault Reports system fault status (either mode) BI23 BV3
DI Bypass Run Reports motor running status in bypass mode BI24 BV6
Type Name Description Modbus N2 BACnet
AI Last Fault Reports last drive fault 401025 AI17 AV18
AI Previous Fault Reports fault previous to last 401026 AI18 AV19
AI Oldest Fault Reports third-oldest fault 401027 AI19 AV20
Type Name Description Modbus N2 BACnet
AI Last Fault Reports last drive fault 401025 AI2 AV3
AI Warning Word 1 Reports warning word 1 400776 AI3 AV4
AI Warning Word 2 Reports warning word 2 400777 AI4 AV5
