14. Press the OFF key on the drive control panel. Note that the bottom line of the drive
control panel display indicates “Off.”
If the ACH580 Drive and E-Clipse Bypass operate according to these steps, and you
have familiarized yourself with their operation, disconnect and lock out power to
prepare for the next test.
Refer to the Safety instructions section on page v for the warnings all personnel who
do work on the drive, motor cable or motor need to follow.
If the drive does not operate according to these steps, refer to the ACH580-01
Hardware Manual (3AXD50000044839).

ABB ACH580-BDR Specifications

General

Cooling Method	Air-cooled
Product Type	Variable Frequency Drive
Output Current	Varies with power rating
Control Method	Sensorless vector control, Vector control
Communication Protocols	Modbus, Profibus, CANopen, Ethernet/IP
Enclosure Rating	IP21
Mounting Type	Wall-mounted, Floor-mounted
Operating Temperature	-15°C to +50°C (with derating above +40°C)
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95% (non-condensing)
Altitude	Up to 1000 m
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature

Summary

Safety Instructions

General Safety in Installation, Start-up, and Maintenance

Essential safety guidelines for personnel involved in installing, starting up, and maintaining the drive.

Electrical Safety in Installation, Start-up, and Maintenance

Crucial electrical safety precautions for installation, start-up, and maintenance personnel.

Grounding

Installation

Preparing for Installation

Installing the Wiring

Control Panel

Start-up

Procedures for starting up the E-Clipse Bypass, including parameter configuration.

E-Clipse Bypass Functions Overview

Operating Modes

Parameters

Parameter List and Descriptions

Comprehensive list and explanation of bypass parameters, essential for configuration and operation.

Embedded Fieldbus

Communication Setup – EFB

Steps for configuring serial communications using the embedded fieldbus (EFB) for system integration.

Activate Drive Control Functions – EFB

Diagnostics – EFB

Troubleshooting

Serial Communication Diagnostics

Diagnostics

Fault Listing

A detailed table of faults, possible causes, and corrective actions for troubleshooting.

Maintenance

Technical Data
