ACH580 E-Clipse bypass and packaged drive user manual 227
Installation
Ratings and frame size
The charts in the Ratings section of the ACH580-01 Hardware Manual
(3AXD50000044839) list technical specifications, and identify the drive’s frame size.
Note: Some instructions in this document vary, depending on the drive’s frame size.
To read the Ratings table, you need the “Output current rating” entry from the Type
code (see page 226).
Suitable mounting location
For selecting a suitable mounting location for PCR/PDR configurations, refer to:
• The ACH580-01 Hardware Manual (3AXD50000044839), and
• The Technical data section on page 237 in this manual for the appropriate
information on dimensions and weights
• UL (NEMA) Type 3R, Px3R-1...Px3R-4 enclosures are designed to be mounted
on a wall. Mounting these 3R enclosures on an open rack system requires the
use of the supplied 3R enclosure back plates to maintain 3R integrity.
Installing the wiring
•
Wiring requirements
The wiring requirements apply to all ACH580 drives. In particular:
• Use separate, metal conduit runs for the following different classes of wiring:
– Input power wiring.
– Motor wiring.
– Control/communications wiring.
• Properly and individually ground the drive, the motor and cable shields.
