208 ACH580 E-Clipse bypass and packaged drive user manual
Technical data
575 Volt fuses for box enclosures
ACH580-BxR-065A-4 65 50 R4 Class T 90A Class J 100A
ACH580-BxR-077A-4 77 60 R4 Class T 100A Class J 100A
ACH580-BxR-096A-4 96 75 R5 Class T 150A Class J 225A
ACH580-BxR-124A-4 124 100 R6 Class T 200A Class J 300A
ACH580-BxR-156A-4 156 125 R7 Class T 225A Class J 350A
ACH580-BxR-180A-4 180 150 R7 Class T 300A Class J 350A
ACH580-BxR-240A-4 240 200 R8 Class T 350A Class J 400A
1) “BxR” represents both BCR and BDR.
Type Code
1
Nominal Output
Ratings
Base
Drive
Frame
Size
Internal Drive
Fuse Rating
External Fuse for
Disconnect Option
Drive
Current
Package
Power
Class
Max
Current
Rating
Class
Max
Current
Rating
AHP
575 Volts
2
ACH580-BxR-02A7-6 2.7 2 R2 Class CC 15A Class J 15A
ACH580-BxR-03A9-6 3.9 3 R2 Class CC 15A Class J 15A
ACH580-BxR-06A1-6 6.1 5 R2 Class CC 15A Class J 15A
ACH580-BxR-09A0-6 9 7.5 R2 Class CC 15A Class J 20A
ACH580-BxR-011A-6 11 10 R2 Class CC 15A Class J 25A
ACH580-BxR-017A-6 17 15 R2 Class CC 30A Class J 40A
ACH580-BxR-022A-6 22 20 R3 Class T 40A Class J 50A
ACH580-BxR-027A-6 27 25 R3 Class T 40A Class J 60A
ACH580-BxR-032A-6 32 30 R3 Class T 40A Class J 60A
ACH580-BxR-041A-6 41 40 R5 Class T 50A Class J 100A
ACH580-BxR-052A-6
3
52 50 R5 Class T 80A Class J 100A
ACH580-BxR-062A-6 62 60 R5 Class T 80A Class J 150A
ACH580-BxR-077A-6 77 75 R5 Class T 100A Class J 175A
ACH580-BxR-099A-6 99 100 R7 Class T 150A Class J 225A
ACH580-BxR-125A-6 125 125 R7 Class T 175A Class J 300A
ACH580-BxR-144A-6 144 150 R8 Class T 200A Class J 350A
1) “BxR” represents both BCR and BDR.
2) BCR is rated 600Y/347V unless otherwise specified. For use on a solidly grounded Wye source only.
3) BCR supports Delta network configuration.
Type Code
1
Nominal Output
Ratings
Base
Drive
Frame
Size
Internal Drive
Fuse Rating
External Fuse for
Disconnect Option
Drive
Current
Package
Power
Class
Max
Current
Rating
Class
Max
Current
Rating
AHP
