ABB ACH580-BDR User Manual

240 ACH580 E-Clipse bypass and packaged drive user manual
Technical data
Branch circuit protection
Input power is connected to the ACH580 with E-Clipse Bypass through a door
interlocked disconnect switch or circuit breaker. Neither of these inputs are fused.
The branch circuit that provides power to the ACH580 with E-Clipse Bypass with
disconnect switch must include the specified external fuses to provide short circuit
and ground fault protection for the motor in the bypass mode.
When connected to a 240V or 480V power source, the ACH580 with E-Clipse
Bypass with the circuit breaker option is suitable for use on a circuit capable of
delivering not more than 100,000 RMS symmetrical amperes. When connected to a
600V power source, PCR configurations are suitable for use on a circuit capable of
delivering not more than 10,000 RMS symmetrical amperes (75-150 HP), and not
more than 25,000 RMS symmetrical amperes (2-60 HP).
Fuses
Note: The UL listed drive fuses in the table are provided in the purchased product.
• Replacement fuses are required to be of the same class, current rating, and
voltage rating. Fuses from other manufacturers can be used if they are 600V
rated and meet the specifications given in the table.
• Fuses with higher current rating than specified must not be used.
208 Volt fuses for packaged drive
208 Volt
Nominal Output
Range
Base
Drive
Frame
Size
Internal Drive
Fuse Rating
External Fuse for
Disconnect Option
Type Code
1
Drive
Current
Packag
e Power
A HP Class
Current
Rating
Class
Max Current
Rating
ACH580-PxR-04A6-2 4.6 1 R1 Class CC 15A N/A N/A
ACH580-PxR-06A6-2 6.6 1.5 R1 Class CC 15A N/A N/A
ACH580-PxR-07A5-2 7.5 2 R1 Class CC 15A N/A N/A
ACH580-PxR-10A6-2 10.6 3 R1 Class CC 15A N/A N/A
ACH580-PxR-017A-2 16.7 5 R1 Class CC 30A N/A N/A
ACH580-PxR-024A-2 24.2 7.5 R2 Class CC 30A N/A N/A
ACH580-PxR-031A-2 30.8 10 R2 Class T 40A N/A N/A
ACH580-PxR-046A-2 46.2 15 R3 Class T 80A N/A N/A
ACH580-PxR-059A-2 59.4 20 R3 Class T 80A N/A N/A
ACH580-PxR-075A-2 74.8 25 R4 Class T 100A N/A N/A
ACH580-PxR-088A-2 88 30 R5 Class T 110A N/A N/A
ACH580-PxR-114A-2 114 40 R5 Class T 150A N/A N/A
ACH580-PxR-144A-2 143 50 R6 Class T 200A N/A N/A
ACH580-PxR-169A-2 169 60 R7 Class T 250A N/A N/A
ACH580-PxR-211A-2 211 75 R7 Class T 300A Class J or RK1 400A
ACH580-PxR-248A-2 248 100
2
R8 Class T 350A Class J or RK1 400A
1) “PxR” represents both PCR and PDR.
2) 100 HP @ 230V
