ACH580 E-Clipse bypass and packaged drive user manual 205
Technical data
Branch circuit protection
Input power is connected to the ACH580 with E-Clipse Bypass through a door
interlocked disconnect switch or circuit breaker. Neither of these inputs are fused.
The branch circuit that provides power to the ACH580 with E-Clipse Bypass with
disconnect switch must include the specified external fuses to provide short circuit
and ground fault protection for the motor in the bypass mode.
When connected to a 240V or 480V power source, the ACH580 with E-Clipse
Bypass with the circuit breaker option is suitable for use on a circuit capable of
delivering not more than 100,000 RMS symmetrical amperes. When connected
to a 600V power source ABB E-Clipse units provided with a circuit breaker,
VCR and BCR configurations, are suitable for use on a circuit capable of
delivering not more than 10,000 RMS symmetrical amperes.
Fuses
Note: The UL listed drive fuses in the table are provided in the purchased product.
• Replacement fuses are required to be of the same class, current rating, and
voltage rating. Fuses from other manufacturers can be used if they are 600V
rated and meet the specifications given in the table.
• Fuses with higher current rating than specified must not be used.
208/230 Volt fuses for vertical enclosures
Type Code
1
Nominal Output Ratings
Base
Drive
Frame
Size
Internal Drive
Fuse Rating
External Fuse for
Disconnect Option
Drive
Current
Package
Power
Class
Max
Current
Rating
Class
Max
Current
Rating
AHP
208/230 Volts
ACH580-VxR-04A6-2 4.6 1 R1 Class CC 15A Class J 15A
ACH580-VxR-06A6-2 6.6 1.5 R1 Class CC 15A Class J 15A
ACH580-VxR-07A5-2 7.5 2 R1 Class CC 15A Class J 20A
ACH580-VxR-10A6-2 10.6 3 R1 Class CC 15A Class J 25A
ACH580-VxR-017A-2 16.7 5 R1 Class CC 30A Class J 40A
ACH580-VxR-024A-2 24.2 7.5 R2 Class CC 30A Class J 45A
ACH580-VxR-031A-2 30.8 10 R2 Class T 40A Class J 60A
ACH580-VxR-046A-2 46.2 15 R3 Class T 80A Class J 100A
ACH580-VxR-059A-2 59.4 20 R3 Class T 80A Class J 100A
ACH580-VxR-075A-2 74.8 25 R4 Class T 100A Class J 100A
1) “VxR” represents both VCR and VDR.
