54 ACH580 E-Clipse bypass and packaged drive user manual
Application macros
Retrofit macro
Parameters Changed Relative to HVAC Default
* Smoke Control (Override1) is a fixed input. Closing Digital Input 6 will place the E-Clipse Bypass in Smoke
Control mode which may reassign the function of the other Digital Inputs. Refer to the Smoke Control
(Override1) documentation.
Parameter Number Description Setting
1602 Damper End Switch
PERMISSIVE
DI2
1701 Refer to page 37
OVERRIDE 2 (Advanced Override)
DI5
Retrofit
Speed Reference / Process Setpoint
Process Feedback Signal
ACH580 CONTROL BOARD
E-CLIPSE BYPASS CONTROL BOARD
Terminal for Signal Cable Shield
Analog Input Common
Analog Input 2
10V / 10mA Reference Voltage for Potentiometer
Analog Input Common
Analog Input 1
X1
1
1
5
4
3
2
6
2
5
4
3
6
7
10
9
8
11
X2
25
23
22
21
20
24
19
18
17
16
15
14
13
12
+24VDC
+24VDC
Digital Input Common
GND
Digital Input 1 (Parameter 1601) START/STOP
Digital Input 2 (Parameter 1602) RUN PERMISSIVE
Digital Input 3 (Parameter 1603) INTERLOCK 1
Digital Input 4 (Parameter 1604, 07)
Digital Input 5 (Parameter 1605) OVERRIDE 2 (E-Bypass Retrofit)
Digital Input 5
(Fixed) SMOKE CONTROL* (Override 1)
Relay Output 1 (Parameter 1401) BYP NOT FLT
Default Operation: Bypass Not Faulted 11 connected to 13
Bypass Faulted 11 connected to 12
Relay Output 2 (Parameter 1404)
SYS RUNNING
Default Operation: System Running 14 connected to 16
Relay Output 3
(Parameter 1407)
SYS STARTED
Default Operation: System Started 17 connected to 19
Relay Output 4
(Parameter 1410)
BYPASS SEL
Default Operation: Bypass Selected 20 connected to 22
Relay Output 5
(Parameter 1413)
BYPASS AUTO
Default Operation: Bypass In Auto 23 connected to 25
Customer Auto Start
Firestat, Freezestat, High Static Switch
X2
Formerly Fireman’s Override
Damper End Switch
To Damper Actuator
NOT SEL
Formerly Bypass Override
