226 ACH580 E-Clipse bypass and packaged drive user manual
Installation
Preparing for installation
Drive identification
Drive label
To identify the type of device you are installing, refer to the type code number on the
device identification label.
• Wall mounting base drives – label attached on the side surface of the enclosure.
• Packaged drive with screw cover – label on side surface of the enclosure.
• Enclosure with hinged cover/door – label on inside surface of the cover/door.
• 3R enclosure with hinged cover/door – label attached to outside surface on the
left side of enclosure.
Type code
Use the following to interpret the type code found on the identification label.
ACH580-PCR-012A-4 +…+…
AC, HVAC Drive = 580 Product Series
Construction
01 = Base Drive
BCR = E-Clipse Bypass with circuit breaker
BDR = E-Clipse Bypass with disconnect switch
PCR = Packaged Drive with circuit breaker
PDR = Packaged Drive with disconnect switch
VCR = Vertical bypass with circuit breaker
VDR = Vertical bypass with disconnect switch
VFD output current rating (See ratings chart for details)
Voltage rating
2 = 208…240 VAC
4 = 440…480 VAC
6 = 575…600 VAC
Enclosure protection class
No specification = UL (NEMA) Type 1
+B056 = UL (NEMA) Type 12
+B058 = UL (NEMA) Type 3R
Power options
+E213 = Line reactor (PxR or BxR Configurations)
+F267 = Service switch (VxR or BxR Configurations)
Input/Output option modules
+L501 = Ext 24V DC/AC and digital I/O Extension
+L512 = 115/230 V digital input interface
+L523 = Ext 24V and isolated PTC Interface
Fieldbus adaptors
+K451 = DeviceNet Adapter
+K452 = LonWorks Adapter
+K454 = Profibus Adapter
+K462 = ControlNet Adapter
+K465 = BACnet/IP (2-port) Adapter (PxR or -01 configurations)
+K475 = Ethernet Adapter
Keypad
+J429 = Control panel with Bluetooth® interface
