224 ACH580 E-Clipse bypass and packaged drive user manual
Installation
The following is a typical power diagram.
Application
This manual contains supplemental information that is unique to ACH580 input
disconnect configurations (PCR or PDR). Refer to the ACH580-01 Hardware Manual
(3AXD50000044839) for all other information.
The following shows the front view of the ACH580 Drive with Input Disconnect
standard configurations, and identifies the major components.
ACH580
Drive
Motor
3
3
Disconnect Switch
or Circuit Breaker
Drive Input
Fuses
Drive With Input Disconnect
3 Phase
Input Power
UL (NEMA) Type 3R
Control Panel with
Hinged Cover
UL (NEMA) Type 3R Enclosures
ACH580 Drive
Operating Handle
ACH580 Drive
for Disconnect Switch
or Circuit Breaker
UL (NEMA) Type 1and UL (NEMA) Type 12
Control Panel
Vertical Construction
Enclosures
UL (NEMA) Type 1 and UL (NEMA) Type 12
Hinged Door Wall Mount Enclosures
