ACH580 E-Clipse bypass and packaged drive user manual 59
Parameters
Parameters
Parameter list and descriptions
Parameter data is specific to bypass firmware version.
Group 01: Actual Data
Group 01: Actual Data
Code Name Resolution Range Default Description
0101 MOTOR CURR 0.1 A — Display motor current in any mode.
0102 INPUT VOLT 1 V — Average of line-line input voltages
0103 DI STATUS 1 000000 - 111111 — DI1-> 110010 <- DI6
0104 RO STATUS 1 00000 - 11111 — RO1-> 11001 <- RO5
0105 PCB TEMP 0.1 ºC — Temperature of bypass board
0106 KW
HOURS (R)
1 kWh 0 - 65535 0 Bypass-mode kilowatt hours
(resettable).
0107 COMM RO 1 0-FFFFh — Serial link control word that can be
linked to relay output control (see
group 14)
0108 RUN TIME(R) 1 hr 0 - 65535 hr 0 Bypass-mode run time (resettable).
0109 ON TIME 1(R) 1 day 0 - 65535 days 0 Total power on time of bypass, days
(resettable)
0110 ON TIME 2(R) 2sec 00:00:00 -
23:59:58
0 Total power on time of bypass,
hr:min:sec (resettable)
0111 A-B VOLT 1 V — Phase A - Phase B voltage
0112 B-C VOLT 1 V — Phase B - Phase C voltage
0113 C-A VOLT 1 V — Phase C - Phase A voltage
0114 MWH(R)
SAVED
0.001 MWH - 1
MWH
0.001 MWH -
65535 MWH
0 Drive kWh savings over bypass
operation (resettable)
0115 COST SAVED(R) 0.001 K$ - 1 K$ 0.001 K$ - 65535
K$
0 Drive cost savings over bypass
operation (reset by parameter 0114)
0116 CO2 SAVED(R) 0.1 tn 0.1 - 6553.5 tn 0 Drive CO2 savings over bypass
operation (reset by parameter 0114)
0117 KWH SAVE L 1 0 - 65535 0 Calculated drive savings (kWh) =
(65536 x [parameter 0017 +
parameter 0018])/256
0118 KWH SAVE H 1 0 - 65535 0 Calculated drive savings (kWh) =
(65536 x [parameter 0017 +
parameter 0018])/256
(R) Can be reset by pressing UP and DOWN buttons simultaneously when in parameter set mode.
