182 ACH580 E-Clipse bypass and packaged drive user manual
Fieldbus adapter
Generic profile technical data
Overview
The generic profile aims to fulfill the industry-standard drive profile for each protocol
(e.g. PROFIdrive for PROFIBUS, AC/DC Drive for DeviceNet).
Control Word
As described earlier in Control interface the control word is the principal means for
controlling the drive from a fieldbus system. For specific CONTROL WORD content,
see the user’s manual provided with the FBA module.
Status Word
As described earlier in Control interface, the contents of the STATUS WORD is
status information, sent by the drive to the master station. For specific STATUS
WORD content, see the user’s manual provided with the FBA module.
Reference
As described earlier in Control interface, the REFERENCE WORD is a speed or
frequency reference.
Note: REF2 is not supported by the Generic Drive profiles.
Reference scaling
REFERENCE scaling is fieldbus type specific. However, at the drive, the meaning of
a 100% REFERENCE value is fixed as described in the table below. For a detailed
description on the range and scaling of the REFERENCE, see the user’s manual
supplied with the FBA module.
ABB Drives Profile (FBA)
Reference Range
Reference
Type
Scalar Remarks
REF
-32767…
+32767
Frequency -20000 = -(par 46.02)
+20000 = (par 46.02)
Final reference limited
by 30.13/30.14
Speed -20000 = -(par 46.01)
+20000 = (par 46.01)
Final reference limited
by 30.11/30.12
