ABB ACH580-BDR User Manual

6 ACH580 E-Clipse bypass and packaged drive user manual
Installation
Preparing for installation
Drive identification
Drive labels
To determine the type of drive you are installing, refer to either:
• Serial number label attached on upper part of the
chokeplate between the mounting holes.
• Type code label attached on the heat sink – on the
right side of the unit cover.
Type code
Use the following chart to interpret the type code found on either label.
ACH580-BCR-012A-4 +…+…
AC, HVAC Drive = 580 Product Series
Construction
01 = Base Drive
BCR = E-Clipse Bypass with circuit breaker
BDR = E-Clipse Bypass with disconnect switch
PCR = Packaged Drive with circuit breaker
PDR = Packaged Drive with disconnect switch
VCR = Vertical bypass with circuit breaker
VDR = Vertical bypass with disconnect switch
VFD output current rating (See ratings chart for details)
Voltage rating
2 = 208…240 VAC
4 = 440…480 VAC
6 = 575…600 VAC
Enclosure protection class
No specification = UL (NEMA) Type 1
+B056 = UL (NEMA) Type 12
+B058 = UL (NEMA) Type 3R
Power options
+E213 = Line reactor (PxR or BxR Configurations)
+F267 = Service switch (VxR or BxR Configurations)
Input/Output option modules
+L501 = Ext 24V DC/AC and digital I/O Extension
+L512 = 115/230 V digital input interface
+L523 = Ext 24V and isolated PTC Interface
Fieldbus adaptors
+K451 = DeviceNet Adapter
+K452 = LonWorks Adapter
+K454 = Profibus Adapter
+K462 = ControlNet Adapter
+K465 = BACnet/IP (2-port) Adapter (PxR or -01 configurations)
+K475 = Ethernet Adapter
Keypad
+J429 = Control panel with Bluetooth® interface
ACH580-BCR-316A-4
S/N 2090501769
S/N 2090501769
ACH580–BCR–240A-4
Input 3PH 50...60 Hz Output 3PH 0...500 Hz
Voltage(U1) 440...480 Vac Voltage(U2) 0...U1 Vac
Current(I1n) 240 A Current(I2n) 240 A
Short Circuit 100 kA
Power(Pn) 200 Hp
ABB Inc.
Made in the USA of foreign parts MTR OL INCL: SEE MANUAL
Mfg. Date: xx-xxxx-20xx Orig. Drive Firmware: V.2.05.0.0
Orig. Bypass Firmware: V.1.01B
Schematic: 3AUA0000014954
E-Clipse Package Rating
VFD Rating

ABB ACH580-BDR Specifications

General

Cooling Method	Air-cooled
Product Type	Variable Frequency Drive
Output Current	Varies with power rating
Control Method	Sensorless vector control, Vector control
Communication Protocols	Modbus, Profibus, CANopen, Ethernet/IP
Enclosure Rating	IP21
Mounting Type	Wall-mounted, Floor-mounted
Operating Temperature	-15°C to +50°C (with derating above +40°C)
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95% (non-condensing)
Altitude	Up to 1000 m
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
